    Zhejiang jeffel Environmental Science and Technology Co., Ltd.was specializes in the R&D, industry manufacture, engineering application and market promotion of the materials and products used for filtration, separation and purification. Since its inception, which has always focused on research and development to promote a variety of new materials and products were separated by filtration, the polymer separation membrane materials and equipment.

    材质 | Materia

    聚丙烯|PP,食品级ABS|food-grade ABS

    滤芯形式 | Form
    中空纤维膜过滤|Hollow fiber filtration
    初期流量 | Initial flow rate
    180 L/h(8寸);200 L/h(10寸)(0.1Mpa,25℃)
    过水量 | Filtration Capacity
    >5400L (shanghai tap water, 0.1Mpa,25℃)
    工作温度 | Operating temperature
    4~40(℃)
    工作最大压差 | Maximum operating pressure
    0.4 MPa
    规格 | Specifications
    D=50mm, L=5 inch,8 inch or 10 inch
    连接方式 | Connection style
    插入式 |Insert type
    适用范围 | Application

    50/70/100 G  RO 膜壳和2812膜壳

    RO shell with 50/70/100 Gallon and 2812 shell
